Eclair series luminaire is the ideal Led lighting solution for any road, street or pedestrian area. Eclair create a more attractive urban living environment and visual comfort for public and residential zones.
It is competitive and efficient and will fit perfectly in retrofit projects as well as new installations on highways, roundabout and urban roads.
The proposed Eclair range consists of three sizes. The Eclair 1 up to 48 LED chips is good choice for service roads , lighting residential streets, ground park & car parking lots. The Eclair 2 up to 80 LEDs is ideally suited for urban roads, lighting collateral streets, and car parks, while the Eclair 3 up to 144 LEDs is perfect for avenues, large roads and motorways.
  • IP66
  • IK09
  • Class I
  • Meets CE safety standards, Rohs compliant
General Specifications
Car Parks, Main Road, Motorways, Park Lighting, Parking, Pedestrian Area, Residential, Roadways
Product Type
Street Light
LED Current mA
350, 525, 700

Technical Data
Post-top Mount
Die-cast aluminum
Body Color
EN1706 AC 47100 powder painted
Extra clear tempered glass. Anti-reflective glass in option
IP Protection
Ambient temperature
Ta -40°C - Ta +55°C
Gear Access
Free tool access
Gear Tray
Removable without tool

4 to 10 m, 4 to 14 m, 8 to 30 m

Optical Data
Light Source
Light Distribution
All distributions compatible with the 2x2 street lenses from Ledil
Color Rendering Index
Ra> 70
Color Temperature (CCT)
3000K, 4000K
Average Lamp Life

Electrical Data
Input Voltage/Frequency
120-277V, 50/60Hz, 347-480V, 50/60Hz
Electrical Class
Class I
Driver Mounting
Surge Protection
Integrated surge protection device 10/20kV
Module type
Removable & Future Proof (according to ZHAGA book 15)

Ordering Code

CodeHeightWattageDelivered Output (lm)CCT (K)
ECLAIR 1 3000K 3M 350mA3m51W86953000
ECLAIR 1 4000K 3M 350mA3m51W92114000
ECLAIR 1 3000K 3M 525mA3m78W126673000
ECLAIR 1 4000K 3M 525mA3m78W132994000
ECLAIR 1 3000K 3M 700 mA3m102W158413000
ECLAIR 1 4000K 3M 700 mA3m102W166164000
ECLAIR 2 3000K 5M 350mA5m83W141513000
ECLAIR 2 4000K 5M 350mA5m83W149904000
ECLAIR 2 3000K 5M 525mA5m127W206253000
ECLAIR 2 4000K 5M 525mA5m127W216534000
ECLAIR 2 3000K 5M 700mA5m171W265563000
ECLAIR 2 4000K 5M 700mA5m171W278564000
ECLAIR 3 3000K 9M 350mA9m150W255753000
ECLAIR 3 4000K 9M 350mA9m150W270904000
ECLAIR 3 3000K 9M 525mA9m231W375143000
ECLAIR 3 4000K 9M 525mA9m231W393854000
ECLAIR 3 3000K 9M 700mA9m307W476773000
ECLAIR 3 4000K 9M 700mA9m307W500104000
