Rayon Lighting

General Specifications

Application

Park Lighting, Parking, Suburban Streets, Urban Roads

Product Type

Landscape Lighting

Technical Data

Mounting

Top and Side Entry

Material

Die-cast aluminum

Body Color

Black, Different colors are available upon request, Grey, White

Optics

Lens and super white temper glass.

Diffuser

White temper glass

IP Protection

IP66

Ambient temperature

Ta= max 55°C

Dimensions

Diameter (mm)

490

Height (mm)

109

Width (mm)

689

Optical Data

Wattage

30W, 40W, 50W, 60W, 80W, 100W, 120W, 150W

Delivered Output (lm)

3960, 4800, 6750, 7920, 10400, 12500, 15000, 18000

Efficiency

130-150lm/W

Light Distribution

Type II, Type III

Color Rendering Index

Ra> 70

Color Temperature (CCT)

2700-6500K upon request, 4000K

Average Lamp Life

>100.000hr

Electrical Data

Input Voltage/Frequency

100-277V, 50/60Hz, 108-305V, 50/60Hz

Electrical Class

Class I, Class II

Driver/Transformer

Included

Driver Mounting

Integrated

Control

Dimmable 1-10V, PWM, Five levels dimming, DALI

Surge Protection

Integrated surge protection device 10/20kV

Mains connection

Cut-off connector (Power automatically switch off when opening)

Module type

Philips LED chips (3030/5050)

Ordering Code

Code	Wattage	Delivered Output (lm)	Efficiency
Moon 30W	30W	3960	130-150lm/W
Moon 40W	40W	4800	130-150lm/W
Moon 50W	50W	6750	130-150lm/W
Moon 60W	60W	7920	130-150lm/W
Moon 80W	80W	10400	130-150lm/W
Moon 100W	100W	12500	130-150lm/W
Moon 120W	120W	15000	130-150lm/W
Moon 150W	150W	18000	130-150lm/W
